AV332
A Compact and Affordable Duplex Scanner
The AV332 is a 32ppm/64ipm, duplex sheetfed scanner that is fast, reliable, and affordable for business where scanning plastic ID cards, business cards, documents or other heavy card stock is necessary. With the straight paper path, the scanner supports paper from 27 to 413g/m² (7 to 110 lb ) in weight and in 8.5” x 14” (legal) in size and allow embossed plastic cards such as credit cards, or driver’s license up to 1.25 mm thick to be transmitted smoothly. Ultrasonic multi-feed detection assures you that not a single page of your documents will be lost.
Features
Product Details
High Optical Resolution of 600 dpi
With a high optical resolution of 600 dpi and advanced image processing technology, you can be assured documents can be converted in the highest image quality. In addition, with the build-in CIS (Contact Image Sensor) module, the AV332 series does not require any warm-up time.
Innovative Design to Save Your Space
The AV332 series boast a unique and stylish design as both the input and output paper tray can be folded when not in use. The paper tray also helps to protect the unit from dust. Unlike bulky conventional scanners, the slim AV332 series can be easily carried and fit on a desk without taking up a lot of space.
Powerful Bundled Software Applications
The AV332 series come with TWAIN and ISIS drivers, and are bundled with a suite of powerful software applications that include Avision Button Manager, AVScan , and PaperPort . With Button Manager, you can create searchable PDFs, scan and send images to e-mail, printer, or clouds servers such as Google Drive™, or Evernote® with just a simple press of a button. The AVScan and PaperPort are highly effective image processing and document management software that helps you streamline your task more efficiently.
Features
High scan speed of up to 32 ppm/64ipm at (A4, Color, 300 dpi)
Easy to carry due to the slim design
Support embossed plastic cards
Ultrasonic multi-feed detection ( AV332U )
Professional bundled software applications include Avision Button Manager , AVScan , PaperPort
Earth-friendly LED technology
Compact ADF holds up to 50 pages
Press and scan to cloud servers such as Google Drive, FTP, Evernote, and Microsoft SharePoint via Button Manager
Specifications
General Specification
Technology
Contact Image Sensor (CIS)
Light Source
LED
Document feeding mode
ADF
Optical Resolution (dpi)
600
Output Resolution (dpi)
1200
File Formats
BMP, PNG, GIF, JPEG, Single-Page PDF, Multi-Page PDF, Multi-TIFF, TIFF, RTF, TXT, OCR( for iScan only ), XPS, DOC, XLS, PPT, DOCS, XLSX, PPTX, HTML
Halftone Patterns
Dither and Error Diffusion
Grayscale mode
16-bit input 8-bit output
Color mode
48-bit input 24-bit output
Memory Size
128 MB
Dimensions (WxDxH)
Maximum：282 x 457 x 334 mm (11 x 18 x 13.15 in), Minimum：282 x152 x 165 mm ( 11 x 5.98 x 6.49 in)
Weight
2.5 Kg
Interface
USB 2.0
Power Consumption
Operation < 15 W；Ready < 6 W；Sleep < 1.6 W；Off < 0.27 W
Acoustical Noise
Operation < 52 dB；Ready < 25 dB
Recommended Daily Volume
Up to 5,000 pages
OS Support
Win 7, Win 8, Win 10
Bundled Software
TWAIN Driver, ISIS Driver, Button Manager, PaperPort, AVScan, WIA Driver, WorldCard Team
Avision AV332 Scanner
Features
Ultrasonic paper jam detection
Yes
Long Paper Mode
Up to 200 dpi Color Duplex 240 in. ( 6096 mm )；Up to 300 dpi Color Duplex 218 in. ( 5540 mm )；Up to 600 dpi Color Duplex 59 in. ( 1500 mm )
Card Scan
Embossed card ( Thickness 1.25 mm )
Scan Size
ADF Minimum
74 x52mm(A8) (2.9 x 2.0 in)
ADF Maximum
216 x 356 mm ( Legal )( 8.5 x 14 in. )
ADF Capacity
50 sheets (80 g/m+² or 20 lb. Paper)
Paper Weight (Thickness )
27g ~ 413 g/m² ( 7 to 110 lb )
Scanning Speed
B/W @ 200dpi, A4
Simplex : 40 ppm；Duplex : 80 ipm
B/W @ 300dpi, A4
Simplex : 40 ppm；Duplex : 80 ipm
Color @ 200dpi, A4
Simplex : 40 ppm；Duplex : 80 ipm
Color @ 300dpi, A4
Simplex : 32 ppm；Duplex : 64 ipm
