Avision AD8120U A3 Document Scanner


AD8120U

A Duplex High-Volume Production Scanner



Avision is pleased to announce its release of the high-volume production scanner with a robust 500-page auto document feeder and a blazing scanning speed of up to 120 ppm/240 ipm in Color, Grayscale, and Monochrome. Combining paper protection technology and triple ultrasonic double-feed detection capability, the AD8120U delivers exceptional feeding reliability to maximize your scanning productivity in a small unit.


Avision AD8120U A3 Document Scanner Specs

Avision AD7080 A3 Document Scanner Info


Features




Product Details

High-Volume Daily Duty Cycle

The scanner can be used to scan up to 60,000 pages per day through the 500-page (80 g/m²) automatic document feeder. The data indicates that this scanner is designed to scan document in any application requiring frequent document and hard card scanning.

Dual CIS Design to Handle Wrinkled Documents

Designed to handle even extreme applications, the AD8120U scanner is built-in with two CIS. These CIS give you maximum illumination to help eliminate shadows from wrinkled documents.

Triple Ultrasonic Sensors to Detect Overlapped Paper

Three ultrasonic sensors provide protection against double feeds by detecting and preventing overlapping pages from being fed into the scanner at the same time. Each sensor can be set to ignore or detect specified areas of a document to accommodate pages with labels or attachments.

Staple Detection Technology

Avision's Staple Detection feature automatically stops the scanning process when an unremoved staple is detected. If left undetected, staples could cause errors that compromise the document, cause jams, or damage the device.

Plastic card or ID card uses the straight paper path

To provide scanner users with the most versatile scanning environments, the user has the choice to utilize a "Curved or Straight Paper Path".  By opening the rear cover, users can use the straight path to transport paper to the rear of the unit. To utilize the straight paper path ensures high reliability with plastic card, ID card, thick, long paper, or more fragile documents.

A Large LCD Display

The AD8120U is easy to use through the clear 1.8” LCD display. By selecting your destination and pressing the “Scan” button, the scan can be done and the scanned image can be sent to your specified destination application such as e-mail, printer, or your favorable image-editing software application. Up to nine frequently used scan settings and destinations can be preset for different scanning needs.

Scan to Cloud with Button Manager V2

The AD8120U come with TWAIN and ISIS drivers, and are bundled with a suite of powerful software applications that include Avision Button Manager , AVScan , and PaperPort . With Button Manager , you can complete a scan and send the image directly to cloud servers such as Google Drive, Dropbox, Evernote, FaceBook, or Microsoft SharePoint with a press of a button. You can also save the image to searchable PDF, JPEG, BMP, or GIF file format, and scan to e-mail, or image editing application. In addition, the bundled software applications also include AVScan  and PaperPort which are are highly effective document management software to streamline your task more efficiently.

Features

  • Fast, 120 ppm / 240 ipm scanning in color, grayscale and monochrome ( 300 dpi )

  • Support form document up to 297 x 432 mm (A3)

  • Robust 500-page (80 g/m²) automatic document feeder

  • Daily duty cycle of up to 60,000 sheets

  • Three Ultrasonic sensors to enable or disable detection in different areas of document

  • Staple detection feature

  • Curved or Straight Paper Path

  • Auto crop and deskew a document with the advanced image processing unit to enhance the scanning speed

  • Latest USB 3.1 Gen1 connectivity for faster transmission speed

  • Reverse roller technology delivers outstanding feeding reliability

  • Hard and embossed card scanning up to 1.4 mm in thickness in landscape feeding

  • Press and scan to cloud servers via the bundled software Button Manager

  • Earth-friendly LED technology

  • Long page scanning up to 6000 mm (236”)

  • Auto power off setting




Specifications




General Specification

Technology
Contact Image Sensor ( CIS )

Light Source

LED ( CIS )

Document feeding mode
ADF

Optical Resolution (dpi)
600

Output Resolution (dpi)
1200

File Formats
BMP, PNG, GIF, JPEG, Single-Page PDF,
Multi-Page PDF, Multi-TIFF, TIFF, RTF, TXT,
OCR ( for iScan only ), XPS, DOC, XLS, PPT,
DOCS, XLSX, PPTX, HTML

Halftone Patterns
Dither and Error Diffusion

Grayscale mode
16-bits input 8-bits output

Color mode
48-bits input 24-bits output

Memory size

1 GB

Dimensions (WxDxH)
460 x 446. x 362 mm

Weight
25 kg

Interface
USB 3.1 Gen 1

Power Consumption
Operation : < 115 W
Ready : < 24 W
Sleep : < 2.46 W

Off : < 0.27 W

Acoustical Noise
Operation : < 55 dB
Standby : < 45 dB

Recommended Daily Volume
Up to 60 000 pages

OS Support
Win XP / Vista / Win 7 / Win 8 / Win 8.1 / Win 10

Bundled Software
Twain Driver, ISIS Driver, Button Manager, AVScan, PaperPort 14

Avision AD8120U Scanner

Avision AD8120U Scanner

Features

Ultrasonic paper jam detection

Long paper mode
Up to 200 dpi Color Duplex 236 in. ( 6000 mm )
Up to 300 dpi Color Duplex 218 in. ( 5540 mm )
Up to 600 dpi Color Duplex 59 in. ( 1500 mm )

Card scan

Embossed card ( Thickness 1.25 mm )

Scan Size

ADF Minimum
52 x 74 mm

ADF Maximum
297 x 432 mm ( Legal )( 8.5 x 14 in. )

ADF Capacity
500 sheets

Paper Weight (Thickness )
U-Turn Path : 20 ~ 105 g/m²
( 5 - 28 lb. Bond )
Straight Path : 20 ~413 g/m²
( 5 - 110 lb. Bond )

Scanning Speed

B/W @ 200dpi, A4
Simplex : 120 ppm
Duplex : 240 ipm

B/W @ 300dpi, A4
Simplex : 120 ppm
Duplex : 240 ipm

Color @ 200dpi, A4
Simplex : 120 ppm
Duplex : 240 ipm

Color @ 300dpi, A4
Simplex : 120 ppm
Duplex : 240 ipm
