AD120
A Compact and Affordable Document Scanner
Combining a flatbed scanner with a convenience up to 50-page ADF (70 g/m²), the Avision AD120 is a compact and affordable productivity scanning solution delivering 25 pages per minute at 300 dpi.
Features
Product Details
Easy-to-use button scanning
The AD120 is easy to use through the LCD display and buttons on the panel. By selecting your destination and pressing the “Scan” button, you can scan document to searchable PDF, JPEG, BMP, or GIF file format, and send the scanned image to a preprogrammed destination such as e-mail, printer, image editing software application, or even a cloud server such as Google Drive,Dropbox, Evernote, or Microsoft SharePoint. Scanning is simply that easy!
Compact and earth-friendly design
The AD120 is compact and earth-friendly in design since it uses CIS ( contact image sensor ) technology which requires smaller space and the LED lamp as the light source. The LED lamps are lower power consumption and are designed to last for the life of the scanner, and their bright light renders true illumination to enable accurate color imaging.
Automatic multiple images cropping
In addition, the scanner comes with the convenient feature of multiple images cropping. With this feature, various sizes of documents such as photos, ID Cards, or business cards can be placed on the flatbed and the scanner is able to crop and create multiple images according to the original sizes of the documents in one single scan.
Advanced settings via TWAIN driver
For advanced users who wish to control scan settings and obtain the best image quality, the Avision’s AD120 is able to scan through Avision’s advanced TWAIN user interface from TWAIN-compliant software application. Avision’s TWAIN user interface provides various useful features to enhance your image quality including auto crop and deskew, auto color detection, color matching, color dropout and so on.
Powerful bundled software applications
The Avision AD120 comes with TWAIN and ISIS drivers, and is bundled with a suite of powerful software applications that include Avision Button Manager, AvScan , and PaperPort . With Button Manager, you can scan to searchable PDF, JPEG, BMP, or GIF file format, sent the scanned image to a specified destination such as e-mail, printer, or other application with a press of a button. The AVScan and PaperPort are highly effective image processing and document management software that helps you streamline your task more efficiently.
Features
· Double-sided color documents up to legal size ( 8.5” x 14” )
· Scan speed up to 25 ppm / 50 ipm in both color or mono mode
· Easy-to-use operational panel
· ADF maximum capacity up to 50 pages of 70g paper
· 1200 dpi true optical resolution
· TWAIN driver provides auto color detection, auto crop, deskew and
thresholding image-enhancing features
· Ultrasonic multi-feed detection provides efficient multi-page scanning
uninterruptedly
· Long page scanning up to 36” ( 200 dpi )
· LED light source requires no warm-up time
· Deliver color, grayscale, or black and white image simultaneously in one scan
· Weight : 2.7 kgs
Specifications
General Specification
Technology
Contact Image Sensor ( CIS )
Light Source
LED ( CIS )
Document feeding mode
Flatbed and ADF
Optical Resolution (dpi)
FB: optical resolution 1200dpi
ADF: optical resolution 600dpi,
interpolated resolution 1200dpi
File Formats
BMP, PNG, GIF, JPEG, Single-Page PDF,
Multi-Page PDF, Multi-TIFF, TIFF, RTF,
TXT, OCR ( for iScan only ), XPS, DOC,
XLS, PPT, DOCS, XLSX, PPTX, HTML
Halftone Patterns
Dither and Error Diffusion
Grayscale mode
16-bits input 8-bits output
Color mode
48-bits input 24-bits output
Memory size
64 MB
Dimensions (WxDxH)
402 x 330 x 112 mm
Weight
2,7 kg
Interface
USB 2.0 ( USB 3.0 compatible )
Power Consumption
Operation : < 10 W
Ready : < 5 W
Sleep : < 2.9 W
Off : < 0.23 W
Recommended Daily Volume
Up to 1500 pages
OS Support
Win XP / Vista / Win 7 / Win 8 / Win 8.1 / Win 10
Bundled Software
Twain Driver, ISIS Driver, Button Manager, AVScan,
PaperPort 14
Avision AD120 Scanner
Features
Long paper mode
Up to 300 dpi Color simplex
Scan Size
ADF Minimum
76.2 x 148 mm
ADF Maximum
216 x 356 mm
ADF Capacity
50 sheets
Paper Weight (Thickness )
60 ~ 110 g/m² ( 16 ~ 28 lb. )
Scanning Speed
B/W @ 200dpi, A4 ADF : Simplex : 25 ppm ; Duplex : 50 ipm
Flatbed : 4.5 sec / 14.8 sec ( Include Backhome )
B/W @ 300dpi, A4 ADF : Simplex : 25 ppm ; Duplex : 50ipm
Flatbed : 4.5 sec / 14.8 sec ( Include Backhome )
Color @ 200dpi, A4 ADF : Simplex : 25 ppm ; Duplex : 50ipm
Flatbed : 4.5 sec / 14.8 sec ( Include Backhome )
Color @ 300dpi, A4 ADF : Simplex : 25 ppm ; Duplex : 50ipm
Flatbed : 4.5 sec / 14.8 sec ( Include Backhome )
Downloads
Downloads
Simply click on the relevant link to start downloading or right click and select ‘Save link as’ and choose where to download it on your PC / device.
Brochures
User Manuals
English
Spanish
French
Portuguese
Drivers
AD120 VB.23 27MB Win XP, Win Vista, Win 7, Win 8, Win 10
