AD345G

A Fast and Affordable Scanner

The AD345G is 60 page-per-minute, duplex scanner that are fast, reliable, and affordable for business where scanning plastic ID cards, business cards, documents or other heavy card stock are necessary. Embedded with Avision-developed image processor, the scanned image can be automatically cropped, straightened, and optimised with enhanced speed.





Features




Product Details

Color, and Graphical LCD Display

The AD345G series are easy to use through the LCD display and buttons on the panel. By selecting your destination and pressing the “Scan” button, the scan can be done and the scanned image can be sent to your specified destination application such as e-mail, printer, or your favorable image-editing software application. Up to nine frequently used scan settings and destinations can be preset for different scanning needs.

A Duplex Scanner Suited for Document and Cards

Thanks to the advanced straight paper path and image processing technology, mixed batches of documents with varies sizes and weights can be scanned, appropriately cropped, deskewed, and ready to use. Scan size accepts paper from receipts (2” x 2”) to business document (8.5 x 14 in.). The auto document feeder is also robust enough to feed paper up to 413 g/m2 (110 lbs) and embossed hard cards such as ID cards, credit cards, driver’s license, and health insurance card up to 1.25mm in thickness.

Reverse Roller Enhances Feeding Reliability

Designed with the innovative reverse roller for advanced paper separation capability, the AD345G series delivers outstanding feeding reliability and operating productivity by effectively reducing the risk of a multi-feed or paper jam.

Ultrasonic Multi-Feed Detection

With the ultrasonic multi-feed detection capability, the scanner allows you to set overlapped paper by detecting paper thickness between documents. The ultrasonic function can be turned off when scanning document with labels, sticky notes, or taped receipts. This innovative design prevents double feeding and effectively scans documents of different weights or thickness.

Compact Design to Save Your Space

The AD345G series features a unique and stylish design as both the input and output paper tray can be folded when not in use. The paper tray also helps to protect the unit from dust. Unlike bulky conventional scanners, the slim AD345G series can be easily carried and fit on a desk without taking up a lot of space.

Powerful Bundled Software Applications

The AD345G series come with TWAIN and ISIS drivers, and are bundled with a suite of powerful software applications that include Avision Button Manager, AVScan , and PaperPort . With Button Manager, you can create searchable PDFs, scan and send images to e-mail, printer, or clouds servers such as Google DriveTM, or Evernote® with just a simple press of a button. The AVScan and PaperPort are highly effective image processing and document management software that helps you streamline your task more efficiently.



Features

  • Fast, 60ppm/120ipm scanning in color, grayscale and monochrome (200 dpi)

  • Fast, 45ppm/90ipm scanning in color (300 dpi)

  • Auto crop and deskew a document with the advanced Avision-developed image processing unit to enhance the scanning speed

  • Support form paper up to 8.5 x 14 in.

  • Daily duty cycle up to 10,000 sheets

  • Robust 100-page automatic document feeder (80 g/m2, 20 lb)

  • Reverse roller technology delivers outstanding feeding reliability

  • Hard and embossed card scanning up to 1.25 mm in thickness in portrait or landscape feeding

  • Press and scan to cloud servers via the bundled software Button Manager V2

  • Earth-friendly LED technology

  • Long page scanning: 1500 mm (59”) (600 dpi,color) / 5540 mm (218”) (200 dpi,color)

  • hardware JPEG Compression, Compression TIFF (JPEG(7), CCITT G4, LZW), Compression PDF

  • Auto power off setting



Specifications




General Specification

Technology

Contact Image Sensor (CIS)

Light Source

LED

Document feeding mode

ADF

Optical Resolution (dpi)

600

Output Resolution (dpi)

1200

File Formats

BMP, PNG, GIF, JPEG, Single-Page PDF, Multi-Page PDF, Multi-TIFF, TIFF, RTF, TXT, OCR( for iScan only ), XPS, DOC, XLS, PPT, DOCS, XLSX, PPTX, HTML

Halftone Patterns

Dither and Error Diffusion

Grayscale mode

16-bit input 8-bit output

Color mode

48-bit input 24-bit output

Memory Size

512MB SDRAM

Dimensions (WxDxH)

Maximum:316 x 680 x 239 mm ( 12.4 x 26.8 x 9.4 in. ), Minimum:316 x 191 x 168 mm ( 12.4 x 7.5 x 6.6 in. )

Weight

4.3 kg ( 9.5 lb. )

Interface

USB3.2 Gen1x1

Power Consumption

Operation < 38 W;Ready < 6 W;Sleep < 1.8 W;Off < 0.2 W

Acoustical Noise

Operation < 52 dB;Ready < 25 dB

Recommended Daily Volume

Up to 10,000 sheets

OS Support

Win 7, Win 8, Win 10

Bundled Software

TWAIN Driver, ISIS Driver, Button Manager, PaperPort, AVScan, WIA Driver

Avision AD345 Scanner

Features

Ultrasonic paper jam detection

Yes

Long Paper Mode

Up to 200 dpi Color Duplex 240 in. ( 6096 mm );Up to 300 dpi Color Duplex 218 in. ( 5540 mm );Up to 600 dpi Color Duplex 59 in. ( 1500 mm )

Card Scan

Embossed card ( Thickness 1.25 mm )

Scan Size

ADF Minimum

50 x 50 mm

ADF Maximum

216 x 356 mm ( Legal )( 8.5 x 14 in. )

ADF Capacity

100 sheets ( A4 : 80 g/m² or 20 lb. )

Paper Weight (Thickness )

27g ~ 413 g/m² ( 7 to 110 lb )

Scanning Speed

B/W @ 200dpi, A4

Simplex : 60 ppm;Duplex :120 ipm

B/W @ 300dpi, A4

Simplex : 60 ppm;Duplex : 120 ipm

Color @ 200dpi, A4

Simplex : 60 ppm;Duplex : 120 ipm

Color @ 300dpi, A4

Simplex : 45 ppm;Duplex : 90 ipm
